Mechanical Seal Spares

Carbon Graphite Silicon Carbide Tungsten Carbide Industrial Ceramic Teflon & Ptfe O-Rings & Gaskets Rubber Oil Seals Hardware Products

Tungsten Carbide(Nickel Bonded)

Tungsten carbide is frequently employed for seal faces owing to its exceptional wear resistance, high fracture strength, superior thermal conductivity, and minimal thermal expansion coefficient. It is recognized as the premier material for enduring heat and fractures among all hard face materials. Tungsten carbide nickel bonded seal faces are widely utilized in numerous industrial applications to effectively prevent leakage between two mating surfaces.

Tungsten Carbide(Cobalt bonded)

Tungsten carbide is extensively utilized as a seal face owing to its exceptional wear resistance, high fracture strength, superior thermal conductivity, and minimal thermal expansion coefficient. It stands out as the optimal material for heat and fracture resistance among hard face materials. WC-Co bonded seal faces are prevalent in mechanical seals across diverse industrial applications, especially in pumps and rotating machinery

Technical Properties Of Tungsten Carbide (Nickel Bonded)

Properties	Unit Of Measurement	Values
Nickel (Ni)	%	6
Tungsten Carbide (WC)	%	94
Density	g/cm³	14.0–14.9
Hardness	HRA	>= 88.5
Compressive Strength	N/mm²	5600
Transverse Rupture Strength	N/mm²	2600
Thermal Conductivity	W/m°K	110
Coefficient Of Thermal Expansion	10⁻⁶/°K	6
Max. Use Temperature	°C	1500

Technical Properties Of Tungsten Carbide (Cobalt Bonded)

Properties	Unit Of Measurement	Values
Cobalt (Co)	%	6
Tungsten Carbide (WC)	%	94
Density	g/cm³	14.6–15.0
Hardness	HRA	>= 89.5
Compressive Strength	N/mm²	5400
Transverse Rupture Strength	N/mm²	2000
Thermal Conductivity	W/m°K	80
Coefficient Of Thermal Expansion	10⁻⁶/°K	5
Max. Use Temperature	°C	1600
